74HCT245

74HCT245, Octal 3-STATE Noninverting Bus Transceiver, SOP5.2, 7V, 20mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~1.00

PartNumber:: 74HCT245

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Daisy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-29

From Other Seller

Part Number:74HCT245
US $0.20 - 1.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 74HCT245 is an Octal 3-State Noninverting Bus Transceiver with LSTTL Compatible Inputs. This device may be used as a level converter for interfacing TTL or NMOS outputs to High Speed CMOS inputs. The 74HCT245 is used for 2-way asynchronous communication between data buses. The device has an active-low Output Enable pin, which is used to place the I/O ports into high-impedance states. The Direction control determines whether data flows from A to B or from B to A.

Parametrics

74HCT245 absolute maximum ratings: (1)DC Supply Voltage (Referenced to GND), VCC -0.5 to +7.0V; (2)DC Input Voltage (Referenced to GND), Vin: -0.5 to Vcc +0.5V; (3)DC Output Voltage (Referenced to GND), Vout: -0.5 to Vcc +0.5V; (4)DC Input Current, per Pin, Iin: ±20mA; (5)DC Output Current, per Pin, Iout: ±35mA; (6)DC Supply Current, Vqq and GND Pins, ICC: ±75mA; (7)Power Dissipation in Still Air, PDIP, PD: 750mW; SOIC Package, PD: 500mW; TSSOP Package, PD: 450mW; (8)Storage Temperature, Tstg: -65 to +150℃; (9)Lead Temperature, 1 mm from Case for 10 Secs (PDIP, SOIC, SSOP or TSSOP Package), TL: 260℃.

Features

74HCT245 features: (1)Output Drive Capability: 15 LSTTL Loads; (2)TTL/NMOS Compatible Input Levels; (3)Outputs Directly Interface to CMOS, NMOS and TTL; (4)Operating Voltage Range: 4.5 V to 5.5 V; (5)Low Input Current: 1.0 μA; (6)In Compliance with the Requirements Defined by JEDEC Standard; (7)No. 7A; (8)Chip Complexity: 304 FETs or 76 Equivalent Gates; (9)Pb-Free Packages are Available.
