Product Summary

The AT25320B-SSHL-T is a 32768-/65536-bits of serial electrically-erasable programmable read-only memory (EEPROM) organized as 4096/8192 words of 8-bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT25320B-SSHL-T is available in space-saving 8-lead JEDEC SOIC, 8-lead UDFN, 8-lead XDFN, 8-lead TSSOP, and 8-ball VFBGA packages. The AT25320B-SSHL-T is enabled through the Chip Select pin (CS) and accessed via a three-wire interface consisting of Serial Data Input (SI), Serial Data Output (SO), and Serial Clock (SCK).

Parametrics

AT25320B-SSHL-T absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0 mA.

Features

AT25320B-SSHL-T features: (1)Serial Peripheral Interface (SPI) Compatible; (2)Supports SPI Modes 0 (0,0) and 3, Datasheet Describes Mode 0 Operation; (3)Low-voltage and Standard-voltage Operation, 1.8 (VCC = 1.8V to 5.5V); (4)20MHz Clock Rate (5V); (5)32-byte Page Mode; (6)Block Write Protection, Protect 1/4, 1/2, or Entire Array; (7)Write Protect (WP) Pin and Write Disable Instructions for Both Hardware and Software Data Protection; (8)Self-timed Write Cycle (5ms max); (9)High Reliability, Endurance: One Million Write Cycles; Data Retention: 100 Years; (10)Green (Pb/Halide-free/RoHS Compliant) Packaging Options; (11)Die Sales: Wafer Form, Tape and Reel, and Bumped Wafers.
