Product Summary

The A102+ is a Leaded ceramic multilayer capacitor. The basic capacitor construction consists of ceramic dielectric materials processed into a tape with a typical thickness range from 0.025 to 0.076 mm. Metal electrode patterns are applied using a thick film screening process. The applications of the A102+ include timing, coupling/decoupling, signal comparison and biasing, Mono-axial, capacitors are suitable for automatic insertion equipment.

Parametrics

A102+ absolute maximum ratings: (1)Capacitance range at 1 kHz, 0.5 V: 1000 pF to 1.00 μF; (2)Tolerance on the capacitance: ±20%; +80%/.20%; (3)Maximum capacitance change with respect to capacitance value at 25℃: +22%/-56%; (4)Rated DC voltage: 50 and 100 V; (5)Dielectric strength: 250% of rated voltage; (6)Insulation resistance at rated voltage: 10000 MΩ or 1000 MΩ × μF, whichever is less at rated voltage within 2 minutes of charging; (7)Dissipation factor at 1 kHz, 0.5 V: ≤4%; (8)Operating temperature range: 10 to 85℃; (9)Storage temperature range: 25 ±15℃; (10)Ageing: typical 6% per time decade.

Features

A102+ features: (1)High capacitance per unit volume; (2)Low cost.

Diagrams

A102+ block diagram
