Product Summary
The ML2011 is a GSM single-chip baseband processor.
Parametrics
ML2011 absolute maximum ratings: (1)front-side bus: 0 to 52MHz; (2)Supply voltage: 3V.
Features
ML2011 features: (1)Single 200-pin FBGA device (13 mm x 13 mm); (2)GSM voice handset capabilities; (3)Data capability; (4)GSM single slot up to 14.4 Kbps; (5)Multi-voltage SIM and IrDA compliant interfaces; (6)GSM850, E-GSM900, GSM1800, and GSM1900 bands; (7)Extremely low power design: 3V I/O and 2V core; (8)Two UART serial ports for data/fax/testing; (9)Flexible RF transceiver control interface; (10)Integrated PA controller; (11)APC DAC with ramping RAM; (12)Support straight or multiplexed I&Q; (13)Schedule-based programmable serial control; (14)Power/cost-flexible audio circuitry; (15)Noise suppression and echo cancellation for speakerphone and car phone environments; (16)Sidetone/microphone amplification control; (17)High output speaker driver; (18)Flexible clock rates for processors (0 to 52 MHz); (19)Real-time clock and alarm.
Diagrams
 |
